Eco-Guard Casement & Awning Series
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +70/-75 psf
Made in Florida
Eco-Guard Casement Window Series 500
Crank-out casement and awning impact windows with multipoint hardware.
Outswing aluminum impact casement, 2-3/4 in. frame, +70/-75 psf, LMI+SMI, NFRC-certified, with a stainless operator + multipoint lock.
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +70/-75 psf
Made in Florida
Impact protection, built for South Florida
- Florida Building Code product-approved
- Aluminum frame engineered for strength and durability
- Large-missile impact-rated laminated glass
- Corrosion-resistant finishes for coastal applications
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Corrosion Resistant
Coastal-grade finishes for salt-air durability
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Aluminum
Max Size
37 x 76 in
Design Pressure
+70/-75 psf
Impact Rating
LMI
Sizes & Pressures
| Configuration | Max size | Design pressure |
|---|---|---|
| Outswing Casement (single vent) | 37 x 76 in | +70/-75 psf |
Performance Certifications
- FL41650.R2
- FL21627.R1
- FL41650
Options
Related Products
More models in the Eco-Guard Casement & Awning Series.
Ready to install the Eco-Guard Casement Window Series 500?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other casement models Armor Pro installs.
Frequently Asked Questions
The Eco-Guard Casement Series 500 is an outswing aluminum impact casement that cranks fully open for maximum ventilation and clean, modern sightlines. We spec it where a homeowner wants a full-opening window with contemporary lines rather than a sliding sash. It runs a stainless steel operator with a multipoint lock and is NFRC-certified for energy performance.
The single-vent outswing CW-500 casement is built to a maximum of 37 inches wide by 76 inches tall. Casements are sized to the opening, so we measure your rough opening and confirm the largest available configuration with ECO during the quote. Because it's a single crank-out vent, the whole sash swings clear for airflow.
The outswing CW-500 casement configuration is rated to a design pressure of +90/-130 psf, which is a strong wind-load rating well suited to South Florida coastal exposures. The exact DP that applies depends on the unit size and glass type you choose. We confirm the required and rated design pressure for your specific opening at the time of quote.
The CW-500 offers Glass Type A, a 7/16-inch laminated makeup with a .090-inch Trosifol PVB interlayer over 1/8-inch heat-strengthened lites, as the standard. ECO also offers Glass Type AA, a 15/16-inch insulated laminated unit with PVB for added energy performance, and Glass Type B, a 7/16-inch laminated build using 3/16-inch heat-strengthened lites. We'll help you pick the package that fits your energy and code needs and confirm it on the quote.
The Series 500 casement carries Florida Product Approval FL41650 (current revision FL41650.R2), which documents its impact and design-pressure performance. It is an LMI large-missile-impact unit and is HVHZ-approved, so it is eligible for use in Miami-Dade and Broward's High Velocity Hurricane Zone. We confirm the approval that applies to your specific configuration before installation.
We don't quote a flat price because installed cost depends on the size of the opening, the glass package you choose, and the condition of the existing frame. The CW-500 is an aluminum impact casement with stainless multipoint hardware, which factors into pricing versus a simpler fixed unit. Armor Pro provides a free, no-obligation estimate after measuring your opening.
Both crank open with a hand operator, but a casement is hinged on the side and swings out like a door, while an awning is hinged at the top and projects outward from the bottom. ECO's Series 500 is the outswing casement, the Series 560 is the project-out awning, and the Series 550 is a matching fixed lite. Awnings are popular because they can stay open for ventilation during light rain.
A casement's whole sash swings open, so you get nearly the full opening for ventilation versus the half you get on a single hung, plus a cleaner contemporary sightline with no meeting rail across the glass. The multipoint lock pulls the sash tight against the frame, which helps the seal. The trade-off is the swing-out operation, which we check against walkways and patios during measurement.
Yes. ECO's residential aluminum impact lines carry Miami-Dade Notices of Acceptance and Florida Product Approvals, which makes them eligible to install in the High-Velocity Hurricane Zone (Miami-Dade and Broward counties). The exact wind ratings depend on the specific series, size, and configuration, so we confirm the right product for your opening on the quote. We pull the permit and submit the approval documents as part of every job.
