143 Series Vinyl
Florida DBPR
Approved
Design Pressure +50/-50 psf
NFRC Certified
Made in Florida
EAS 143 Series Double Hung Vinyl
EAS's volume-tier vinyl window family with a 3-1/4 inch fusion-welded frame.
Vinyl double-hung on the 143 Series frame, sized for residential replacement applications outside HVHZ jurisdictions at 50 psf design pressure.
Florida DBPR
Approved
Design Pressure +50/-50 psf
NFRC Certified
Made in Florida
Frame finish
White
Desert Sand
Custom
Built for South Florida homes
The 143 DH is EAS's vinyl double-hung window in the 143 Series, sized for residential replacement applications outside HVHZ jurisdictions. Built on the fusion-welded vinyl frame platform at 50 psf design pressure.
- Florida Building Code product-approved
- Vinyl frame engineered for strength and durability
- Energy-efficient Low-E insulated glass options to control heat gain
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Grille Patterns
Grille Styles
Grids Between Glass (GBG)Simulated Divided Light (SDL)
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Vinyl
Max Size
48 x 72 in
Design Pressure
+50/-50 psf
U-Factor
0.3–0.47
SHGC
0.14–0.6
Visible Trans.
0.15–0.64
Sizes & Pressures
| Configuration | Max size | Design pressure |
|---|---|---|
| Double hung — Fin frame | 48 x 72 in | +50/-50 psf |
| Double hung — Flange frame | 48 x 72 in | +50/-50 psf |
Fin.
Flange.
Glass & Energy Performance
| Glass package | U-Factor | SHGC | VT |
|---|---|---|---|
| Clear / arg90 / clear (DS/DS) - 3/4" IG | 0.46 | 0.61 | 0.64 |
| E366 / arg90 / clear (DS/DS) - 3/4" IG | 0.31 | 0.22 | 0.5 |
| E366 / arg90 / Solargray (DS/DS) - 3/4" IG | 0.31 | 0.21 | 0.34 |
| E340 / arg90 / clear (DS/DS) - 3/4" IG | 0.31 | 0.14 | 0.3 |
| E452 / arg90 / clear (DS/DS) - 3/4" IG | 0.31 | 0.17 | 0.41 |
| Clear / arg90 / lami (DS/DS|090PVB|DS) - 3/4" IG | 0.47 | 0.57 | 0.63 |
| E366 / arg90 / lami (DS/DS|090PVB|DS) - 3/4" IG | 0.34 | 0.22 | 0.49 |
| E366 / arg90 / Solargray-lami (DS/DS|090PVB|DS) - 3/4" IG | 0.34 | 0.21 | 0.33 |
| E340 / arg90 / lami (DS/DS|090PVB|DS) - 3/4" IG | 0.35 | 0.15 | 0.3 |
| E452 / arg90 / lami (DS/DS|090PVB|DS) - 3/4" IG | 0.34 | 0.18 | 0.4 |
U-Factor / SHGC shown without grids; add-grid values vary slightly. Confirm exact ratings for your opening at quote.
Performance Certifications
- FL14593.R9
Options
Related Products
More models in the 143 Series Vinyl.
Ready to install the EAS 143 Series Double Hung Vinyl?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other double hung models Armor Pro installs.
Frequently Asked Questions
No. The 143 DH is a non-impact vinyl double-hung window, and it is not approved for High-Velocity Hurricane Zone (HVHZ) jurisdictions. It is designed for residential replacement applications outside HVHZ areas at a 50 psf design pressure. If you need an impact-rated unit, EAS offers HVHZ-certified casement and awning windows in the same 143 Series under their Bertha Vinyl Impact branding, and we can review the right option with you at quote.
The 143 DH builds up to a maximum of 48 inches wide by 72 inches tall, available in both fin-frame and flange-frame configurations. Both versions carry a design pressure of +50/-50 psf. We confirm the rating and the exact size for your opening when we measure for your free estimate.
Energy performance depends on the glass package you choose. Across the available Low-E and laminated options, the 143 DH ranges from a U-factor of 0.31 to 0.47 and an SHGC of 0.14 to 0.61. For South Florida heat, the E340 clear package reaches a 0.14 SHGC with a 0.31 U-factor, and we can match the glass to your sun exposure and comfort goals.
The 143 DH uses a 3/4-inch insulated glass unit with argon (arg90) fill and offers several Low-E coatings, including E366, E340, E452, and clear, plus Solargray tinting. Laminated glass packages with a PVB interlayer are also available for added durability and sound reduction. We help you pick the package that best balances solar control, visible light, and clarity for your home.
The 143 DH is offered in a standard White frame finish, plus Desert Sand and a Bronze Exterior with White Interior combination. You can also add grids in Grids Between Glass (GBG), Simulated Divided Light (SDL), Colonial, Prairie, or Perimeter patterns. We'll go over finish and grid choices with you so the windows match your home's look.
We don't quote a flat price because installed cost depends on the size of the opening, the glass package you select, the finish and grids, and the condition of the existing frame. The 143 DH is EAS's volume-tier vinyl line, so it's positioned as a value-focused replacement window. Armor Pro provides a free, no-obligation estimate after measuring your openings so the price reflects your actual project.
The 143 Series is EAS's volume-tier vinyl window family, the everyday line for residential replacement. It is built on the same 3-1/4 inch fusion-welded frame as the flagship Bertha line, with a 0.070 inch wall that EAS markets as about 12 percent thicker than most vinyl windows. It is the broadest line in the catalog, covering six operation styles on one frame platform.
Six: single hung, double hung, horizontal roller, picture, casement, and awning. That is the widest operation coverage in the EAS vinyl catalog, which is why it is the workhorse line for a full-home replacement where you want to keep a consistent frame look across different opening types. Single hung is the volume style; the fixed picture model carries the highest design pressure in the line at 80 psf.
Eastern Architectural Systems (EAS) is a Florida manufacturer based in Fort Myers, with roots in the Eastern Metal Supply family. It builds vinyl and aluminum impact-resistant windows and doors for the Florida residential market, and is the maker of the Bertha impact line. EAS has been part of Cornerstone Building Brands since late 2023, though it still operates under its own brand. We install and service EAS products throughout South Florida.
