Scout Aluminum
Florida DBPR
Approved
Design Pressure +50/-50 psf
NFRC Certified
Made in Florida
PGT Scout Aluminum Single Hung SH4000A
PGT's non-impact aluminum value-tier line for builder new-construction projects.
Value-tier non-impact aluminum single-hung in equal and ProView sash configurations on a 2-inch frame. Block-and-tackle balance, powder-coat finish.
Florida DBPR
Approved
Design Pressure +50/-50 psf
NFRC Certified
Made in Florida
Frame finish
Built for South Florida homes
The SH4000A is PGT's Scout value-tier non-impact aluminum single-hung window, available in equal and ProView sash configurations on a nominal 2-inch frame depth. Block-and- tackle balance hardware with a powder-coat finish.
- Florida Building Code product-approved
- Aluminum frame engineered for strength and durability
- Energy-efficient Low-E insulated glass options to control heat gain
- Corrosion-resistant finishes for coastal applications
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Grille Styles
1" Flat/Flat13/16" Grid Between the Glass
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Corrosion Resistant
Coastal-grade finishes for salt-air durability
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Aluminum
Max Size
53.125 x 78 in
Design Pressure
+50/-50 psf
U-Factor
1.09
SHGC
0.25–0.63
Visible Trans.
0.04–0.72
Sizes & Pressures
| Configuration | Min size | Max size | Design pressure |
|---|---|---|---|
| O/X Equal | 13.5 x 23.75 in | 53.125 x 78 in | +50/-50 psf |
Sizes shown are actual DLO frame size.
1/2" flange frame type; integral nail-fin frame type available.
Glass & Energy Performance
| Glass package | U-Factor | SHGC |
|---|---|---|
| Energy Shield | 0.61 | 0.35 |
| Argon/Energy Shield | 0.55 | 0.35 |
| Energy Shield Max | 0.6 | 0.25 |
| Argon/Energy Shield Max | 0.55 | 0.25 |
U-Factor / SHGC shown without grids; add-grid values vary slightly. Confirm exact ratings for your opening at quote.
Performance Certifications
- FL239.R30
Options
Ready to install the PGT Scout Aluminum Single Hung SH4000A?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other single hung models Armor Pro installs.
Frequently Asked Questions
The SH4000A is PGT's Scout value-tier non-impact aluminum single-hung window on a nominal 2-inch frame. In a single-hung, the bottom sash slides up to open while the top sash stays fixed, and it's offered in equal and ProView sash configurations so you can choose a balanced look or a larger viewable area of glass. We install it in South Florida non-HVHZ new-construction and replacement projects where impact glazing isn't required.
No, the SH4000A is a non-impact window. The Scout line is PGT's value tier for projects outside the High-Velocity Hurricane Zone, so it isn't approved for Miami-Dade or Broward openings that require impact glazing. If you need a code-compliant impact single-hung for those areas, the step up is PGT's Sparta SH4100A; we'll confirm which one your jurisdiction and opening require at quote.
In its O/X equal configuration, the SH4000A runs from a minimum of about 13.5 by 23.75 inches up to a maximum of roughly 53 by 78 inches, with a design pressure of +50/-50 psf. That covers most standard bedroom and living-area openings for a non-impact replacement. We'll size the window and confirm the design pressure that fits your opening when we quote.
The SH4000A is offered with PGT's Energy Shield and Energy Shield Max Low-E glass, with U-factors from 0.55 to 0.64 and SHGC ratings from 0.22 to 0.35 depending on the package and grids; the values are based on a 1/2-inch insulated glass unit, and adding argon lowers the U-factor. For South Florida heat, we usually recommend an Energy Shield Max package to hold the SHGC down, and we'll walk you through the choices at quote.
The SH4000A uses block-and-tackle balances to hold the sash and comes standard with a traditional sweep lock, with a bottom lock available, all in a durable powder-coat finish. It's offered in White and Bronze, with grid options of a 1-inch flat grid or a 13/16-inch grille set between the glass. We coordinate the finish and grid with your other Scout windows so the home reads as a set.
There's no single price, because the installed cost depends on the window size, the glass package and grids you select, the frame finish, and the condition of the existing opening. The number of windows and how they tie into the wall also factor into labor. Armor Pro gives a free, no-obligation estimate; we'll measure your openings and price the SH4000A for your project.
No — Scout is PGT's non-impact aluminum value line, so it can't be installed in the High-Velocity Hurricane Zone and doesn't carry impact certification. It's a builder-grade window built for new-construction homes outside the HVHZ where the code does not require impact glazing. If your address falls inside Miami-Dade or Broward, or you want storm protection regardless of jurisdiction, the answer is the impact-rated WinGuard line, not Scout.
Scout is deliberately narrow — four window styles only: single hung, horizontal roller, fixed picture, and architectural shapes, in white or bronze. There's no casement, awning, or sliding door in the Scout line, so a Scout-spec house pulls those openings from a different line. We treat it as a spec-and-builder option: pick the operation style and a standard finish, and it goes in.
PGT has built impact windows and doors in Venice, Florida since 1980 and is the largest impact-window and -door manufacturer in the country. It was the first company to develop impact-resistant products that met Miami-Dade County's hurricane code after Hurricane Andrew, and the line is engineered specifically for Florida conditions. PGT is now part of the MITER Brands family, alongside WinDoor, ECO, and NewSouth, but the products are still made in Florida under the PGT name.
