PGT ClassicVue Max Aluminum Horizontal Roller HR7610A
PGT's premium non-impact aluminum line for Florida coastal non-HVHZ replacement projects.
Premium non-impact aluminum horizontal roller in 2-lite and 3-lite configurations. Tandem stainless rollers with low-friction brass bearings, removable sash.
Miami-Dade NOA
Florida DBPR
Approved
HVHZ
Approved
Design Pressure +65/-130 psf
NFRC Certified
Made in Florida
Frame finish
White
Bronze
Black
Clear Anodize
Custom
Impact protection, built for South Florida
The HR7610A is PGT's ClassicVue Max premium non-impact aluminum horizontal roller window, available in 2-lite and 3-lite configurations. Tandem stainless-steel rollers with low-friction brass bearings in nylon housings, with sash that removes for exterior cleaning.
- Tested & certified to Miami-Dade HVHZ hurricane standards
- Aluminum frame engineered for strength and durability
- Energy-efficient Low-E insulated glass options to control heat gain
- Corrosion-resistant finishes for coastal applications
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Grille Styles
1" Raised/Flat Grid9/16" Flat Grid-Between-the-Glass
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Corrosion Resistant
Coastal-grade finishes for salt-air durability
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Aluminum
Max Size
76 x 76 in
Design Pressure
+65/-130 psf
U-Factor
1.11–1.12
SHGC
0.29–0.68
Visible Trans.
0.13–0.7
Sizes & Pressures
| Configuration | Min size | Max size | Design pressure |
|---|---|---|---|
| OX, XO | 19.75 x 14.625 in | 76 x 76 in | +65/-130 psf |
| XOX 1/4-1/2-1/4 | 42 x 14.625 in | 120 x 63 in | +65/-130 psf |
| XOX 1/3-1/3-1/3 | 35.25 x 18 in / 42 x 14.625 in | 113.625 x 63 in | +65/-130 psf |
Sizes shown are actual DLO frame size.
Glass & Energy Performance
| Glass package | U-Factor | SHGC | VT | CR |
|---|---|---|---|---|
| Blue | 1.12 | 0.48 | 0.6 | 11 |
| Bronze | 1.117 | 0.43 | 0.297 | 11 |
| Clear | 1.115 | 0.675 | 0.695 | 12 |
| Green | 1.115 | 0.545 | 0.635 | 12 |
| Gray | 1.116 | 0.416 | 0.272 | 11 |
U-Factor / SHGC shown without grids; add-grid values vary slightly. Confirm exact ratings for your opening at quote.
Performance Certifications
- 23-0707.07 exp. 2028
- FL242.R35
Options
Related Products
More models in the ClassicVue Max Aluminum.
PGT ClassicVue Max Aluminum Casement CA640A
Casement
See price & specs
PGT ClassicVue Max Aluminum Casement Picture PW640A
Fixed Window
See price & specs
PGT ClassicVue Max Aluminum Picture PW7620A
Fixed Window
See price & specs
PGT ClassicVue Max Aluminum Preferred SGD SGD670A
Sliding Glass Door
See price & specs
Ready to install the PGT ClassicVue Max Aluminum Horizontal Roller HR7610A?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other horizontal roller models Armor Pro installs.
Eastern Architectural Systems
EAS 176 Bertha Horizontal Roller Impact Vinyl
See price & specs
ES Windows
ES Windows Prestige ES-P300 Sliding (TB Retrofit)
See price & specs
ECO Window Systems
Eco-Guard Horizontal Rolling Series 200
See price & specs
Eurocraft
Eurocraft EC-300 Horizontal Slider Window
See price & specs
Frequently Asked Questions
The HR7610A is PGT's ClassicVue Max premium non-impact aluminum horizontal roller window, available in 2-lite (OX/XO) and 3-lite (XOX) configurations. It's a good fit for wide openings where you want a side-to-side sliding sash rather than a window that lifts, such as bedrooms, family rooms, and over kitchen counters. Because it's non-impact, we install it on Florida non-HVHZ coastal and inland homes where the building code does not require impact glazing.
No. The HR7610A is a non-impact window and is not intended for the High-Velocity Hurricane Zone, where laminated impact glass is required by code. It does carry a Miami-Dade Notice of Acceptance (NOA 23-0707.07) and is rated to a design pressure of +65/-130 psf, which speaks to its structural strength against wind load, not impact resistance. If your opening is in the HVHZ, we'll steer you to a PGT WinGuard impact roller instead and confirm the right product at quote.
The 2-lite OX/XO configuration goes up to 76 by 76 inches, the XOX 1/4-1/2-1/4 layout reaches 120 inches wide by 63 inches tall, and the XOX 1/3-1/3-1/3 layout reaches about 113.6 inches wide by 63 inches tall. All three carry a design pressure of +65/-130 psf. We measure each opening and confirm the configuration and rating that fits your wall before we order.
The HR7610A is offered in a range of single-glaze tints, including clear, bronze, gray, green, and SolarBan low-e packages, with U-factors of 1.11 to 1.12 and SHGC values ranging from about 0.32 up to 0.68 depending on the glass. For heat control in South Florida, the SolarBan and gray low-e options drop SHGC to the low 0.30s while keeping good visibility. We'll walk you through the trade-offs between glare, heat, and view and confirm the rated numbers for your selection.
The HR7610A comes standard in White, Bronze, Black, and Clear Anodize aluminum finishes, with custom colors also available. For grids you can choose a 1-inch raised or flat grid, or a 9/16-inch flat grid set between the glass for easier cleaning. We'll match the finish and grid pattern to the rest of your windows so the elevation stays consistent.
There's no flat price, because the installed cost depends on the size, whether you choose a 2-lite or 3-lite configuration, the glass package, and the condition of the existing opening. A wide XOX three-lite unit with a low-e glass upgrade costs more than a standard 2-lite with clear glass. Armor Pro gives a free, no-obligation estimate; we'll measure your openings and price the HR7610A for your project.
No — ClassicVue Max is a non-impact aluminum line, so it can't be installed in the High-Velocity Hurricane Zone of Miami-Dade and Broward, and it doesn't carry the Miami-Dade NOAs the impact lines do. It's built for Florida counties outside the HVHZ where the code does not require laminated impact glazing. Any opening that needs storm certification calls for WinGuard Aluminum instead, which is the impact line above it in the catalog.
ClassicVue Max is the premium non-impact aluminum tier, built to a coastal standard rather than a builder-basic one. It carries the same EnergyShield, EnergyShield Max, and Solar Control Low-E glass packages and the same full four-color aluminum palette as the flagship WinGuard Aluminum line, plus a Limited Lifetime Warranty. The aluminum construction is engineered to resist salt, heat, and moisture. It's the choice for a non-HVHZ home that still wants premium glass and finishes.
PGT has built impact windows and doors in Venice, Florida since 1980 and is the largest impact-window and -door manufacturer in the country. It was the first company to develop impact-resistant products that met Miami-Dade County's hurricane code after Hurricane Andrew, and the line is engineered specifically for Florida conditions. PGT is now part of the MITER Brands family, alongside WinDoor, ECO, and NewSouth, but the products are still made in Florida under the PGT name.
