Eco-Guard 400 Storefront Window

Individual modules in the Series 400 run up to 56-1/2 inches wide by 150-3/4 inches tall, and because it's a modular window-wall system, modules join together to cover much larger commercial openings. We measure the elevation and lay out the module grid that fits your span during the quote. The tall module height is what makes it suited to full-height storefront glazing.

The Series 400 window-wall system is rated to a design pressure of +80/-130 psf, a high wind-load rating well suited to South Florida coastal commercial work. The DP that applies can vary with module size within the system. We confirm the required and rated design pressure for your specific elevation at the time of quote.

Yes. The Series 400 is a large-missile-impact (LMI) and small-missile-impact (SMI) rated system and is HVHZ-approved under Florida Product Approval FL21632 (current revision FL21632.R5), so it is eligible for Miami-Dade and Broward's High Velocity Hurricane Zone. We confirm the approval that applies to your configuration before installation.

Yes. Beyond the standard laminated glazing, the Series 400 offers a SaflexSGP interlayer option, a stiffer structural interlayer that can support higher loads and larger glass. The system uses snap-on glazing beads, which makes the glass serviceable in the field. We'll help you choose the glass package that fits your span and the design pressure your elevation requires.

We don't quote a flat price because installed cost depends on the overall span and module layout, the glass package, and the condition of the existing opening. As a 5-inch commercial impact window-wall system, it's specified differently from individual residential windows. Armor Pro provides a free, no-obligation estimate after measuring your elevation.

Storefront is a heavier-walled aluminum system built for the larger spans, higher duty cycles, and code requirements of commercial ground floors and mixed-use buildings, where a residential window would run out of span or rating. ECO's commercial line includes the 5-inch Series 400 window-wall, the lighter 4-inch Series 450 Frontset, and matching storefront doors. We use these where a project's openings, occupancy, or door traffic call for a commercial assembly.

Yes. The storefront windows (Series 400, 450) and doors (Series 800, 810) use Eco-Guard laminated impact glass on aluminum and carry large-missile and small-missile impact approval, eligible for Miami-Dade and Broward HVHZ installation. The windows run under Florida Product Approval FL21632 and the doors under FL39630, with the Series 400 reaching about +80/-130 psf. We confirm ratings against the project's structural calcs on the quote.

Yes. ECO's residential aluminum impact lines carry Miami-Dade Notices of Acceptance and Florida Product Approvals, which makes them eligible to install in the High-Velocity Hurricane Zone (Miami-Dade and Broward counties). The exact wind ratings depend on the specific series, size, and configuration, so we confirm the right product for your opening on the quote. We pull the permit and submit the approval documents as part of every job.
