Eco-Guard Architectural Fixed Window Series
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +80/-90 psf
Made in Florida
Eco-Guard Architectural Fixed Window Series 300
Tall fixed impact glass for South Florida elevations, up to 120 in.
2-3/4 in. aluminum impact fixed window with concealed fasteners, +80/-90 psf, LMI+SMI, up to 36 x 120 in.
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +80/-90 psf
Made in Florida
Impact protection, built for South Florida
- Florida Building Code product-approved
- Aluminum frame engineered for strength and durability
- Large-missile impact-rated laminated glass
- Corrosion-resistant finishes for coastal applications
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Corrosion Resistant
Coastal-grade finishes for salt-air durability
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Aluminum
Max Size
74 x 120 in
Design Pressure
+80/-90 psf
Impact Rating
LMI
Sizes & Pressures
| Configuration | Min size | Max size | Design pressure |
|---|---|---|---|
| Fixed Window | 24 x 26 in | 74 x 120 in | +80/-90 psf |
Performance Certifications
- FL32389
Related Products
More models in the Eco-Guard Architectural Fixed Window Series.
Comparable from Other Brands
Other fixed window models Armor Pro installs.
Air Master
Air Master Picture Window
See price & specs
Eastern Architectural Systems
EAS 176 Bertha Picture Impact Vinyl
See price & specs
Pella
Pella Lifestyle Fixed / Picture / Specialty Shapes
See price & specs
PGT Custom Windows & Doors
PGT WinGuard Aluminum Casement Picture PW740A
See price & specs
Frequently Asked Questions
The Series 300 (AF-300) is ECO Window Systems' mid-tier aluminum impact fixed (non-operable) window, built on a 2-3/4 inch frame with concealed fasteners for a clean look. It's made for picture openings, transoms, and tall architectural shapes, sitting between the entry Series 70 and the top Series 350 in ECO's fixed-window family. We install it where you want a large, fixed expanse of impact glass, and we often pair it with operable ECO units to build big stacked elevations.
Yes. The Series 300 is a Large Missile Impact (LMI) rated unit and is HVHZ-approved, so it can be used in Miami-Dade and Broward. It carries Florida Product Approval FL32389. We confirm the specific approval and rating for your jurisdiction at the time of quote so the unit is permitted correctly for your opening.
In its fixed configuration the AF-300 goes from a minimum of 24 by 26 inches up to a maximum of 74 by 120 inches, so it reaches a full 10 feet tall. At those sizes it is engineered to a design pressure of +100/-150 psf, which is the wind load the unit resists. We measure your rough opening and confirm the exact size and design pressure your project needs before ordering.
The Series 300 has an aluminum frame, which is what lets it span up to 120 inches tall while staying slim, and it uses concealed fasteners so no screw heads show on the face. ECO offers a range of frame colors and finishes across its line, and we'll go over the available options for the AF-300 when we spec your project.
Yes. Because the AF-300 is a fixed, non-operable picture unit, we frequently combine it with operable ECO products to build large stacked elevations that still give you ventilation. The fixed lite supplies the big uninterrupted glass area while the operable units handle airflow. We design the full elevation with you so the fixed and operating units line up cleanly.
We don't quote a flat price because installed cost depends on the size of the opening, the glass package, and the condition of the existing frame, and the AF-300 can run all the way up to 74 by 120 inches, which affects the number. As an aluminum fixed unit it's typically more economical per square foot than an operable window of the same span. Armor Pro provides a free, no-obligation estimate after measuring your opening.
A fixed (or picture) window doesn't open — it's a sealed lite of glass for light and views where ventilation isn't needed. ECO's architectural fixed family is built for tall and large picture openings, transoms above doors, and specialty shapes like half-rounds and octagons. We commonly pair fixed glass with operable units to build a large stacked elevation.
The family runs from the Series 70 up to the Series 350, which reaches up to 120 inches tall on a 3-3/8 inch frame. Taller and wider picture glass carries higher loads, so the available size narrows as the design pressure climbs. We size each fixed lite against the wind load for its position on the wall and confirm the maximum on the quote.
Yes. ECO's residential aluminum impact lines carry Miami-Dade Notices of Acceptance and Florida Product Approvals, which makes them eligible to install in the High-Velocity Hurricane Zone (Miami-Dade and Broward counties). The exact wind ratings depend on the specific series, size, and configuration, so we confirm the right product for your opening on the quote. We pull the permit and submit the approval documents as part of every job.
