PGT EnergyVue Vinyl Single Hung SH5400
PGT's non-impact vinyl line with the best thermal performance in the PGT residential catalog.
Non-impact vinyl single-hung on a 3-1/2 inch welded vinyl frame with ComfortLift handles. The non-impact counterpart of the WinGuard SH5500.
Miami-Dade NOA
Florida DBPR
Approved
HVHZ
Approved
Design Pressure +65/-130 psf
NFRC Certified
Made in Florida
Frame finish
White
Beige
Bronze
Black
Custom
Impact protection, built for South Florida
The SH5400 is PGT's EnergyVue non-impact vinyl single-hung window, the most common operation style on Florida homes. Built on the 3-1/2 inch welded vinyl frame platform with ComfortLift handles, the non-impact counterpart of the WinGuard SH5500.
- Tested & certified to Miami-Dade HVHZ hurricane standards
- Vinyl frame engineered for strength and durability
- Energy-efficient Low-E insulated glass options to control heat gain
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Grille Patterns
Grille Styles
9/16" Flat Grid-Between-the-Glass13/16" Flat Grid-Between-the-Glass1" Contour Grid-Between-the-Glass
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Vinyl
Max Size
52.125 x 84 in
Design Pressure
+65/-130 psf
U-Factor
0.3
SHGC
0.19–0.29
Visible Trans.
0.11–0.53
Sizes & Pressures
| Configuration | Min size | Max size | Design pressure |
|---|---|---|---|
| O/X Equal | 16.25 x 23.5 in | 52.125 x 84 in | +65/-130 psf |
Sizes shown are actual DLO frame size.
Glass & Energy Performance
| Glass package | U-Factor | SHGC |
|---|---|---|
| Energy Shield | 0.33 | 0.31 |
| Argon/Energy Shield | 0.3 | 0.29 |
| Energy Shield Max | 0.32 | 0.21 |
| Argon/Energy Shield Max | 0.29 | 0.2 |
U-Factor / SHGC shown without grids; add-grid values vary slightly. Confirm exact ratings for your opening at quote.
Performance Certifications
- 25-0520.02 exp. 2030
- FL239.R30
Options
Related Products
More models in the EnergyVue Vinyl Series.
Ready to install the PGT EnergyVue Vinyl Single Hung SH5400?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other single hung models Armor Pro installs.
Frequently Asked Questions
The SH5400 is PGT's EnergyVue non-impact vinyl single-hung window, built on a 3-1/2 inch welded vinyl frame. Single-hung is the most common operation style on Florida homes because the bottom sash raises to vent while the top stays fixed, which is simple, durable, and economical. We install the SH5400 in non-HVHZ counties as a like-for-like replacement for older single-hung windows.
No. The SH5400 is non-impact, so we don't install it inside the High-Velocity Hurricane Zone where the code requires impact glazing. Its direct impact counterpart is PGT's WinGuard SH5500, which we install in HVHZ areas. We'll confirm at quote whether your address requires the impact version.
The SH5400 runs from a minimum of 16.25 by 23.5 inches up to a maximum of about 52.125 inches wide by 84 inches tall in the O/X equal configuration, carrying a +65/-130 psf design pressure rating. That covers most standard Florida window openings as a direct replacement. We'll confirm the exact sizes that fit your rough openings during the free measure.
EnergyVue offers the best thermal performance in PGT's residential catalog, and on the SH5400 we can spec U-factors from 0.29 to 0.33. SHGC drops as low as 0.18 with the Argon/Energy Shield Max package with grids. Glass options run from Energy Shield (U 0.33, SHGC 0.31) up to Argon/Energy Shield Max (U 0.29, SHGC 0.20), and we'll recommend the package that best balances heat rejection and daylight for your home's exposure.
The SH5400 includes a standard sweep latch and vent latch, with an optional vent limiter and the ComfortLift handle that makes raising the sash easier. Frame finishes are White, Beige, Bronze, and Black, plus two-tone Bronze Exterior/White Interior and Black Exterior/White Interior. Grid choices include 7/8" Traditional Simulated Divided Lite and grids-between-the-glass in 9/16" flat, 13/16" flat, or 1" contour.
Installed price depends on the size of each opening, the glass package you choose, and the condition of the existing frames, so there's no flat per-window price. As a PGT installer, Armor Pro provides a free in-home estimate where we measure every opening, confirm the right glass, hardware, and finish, and price the complete installed job. Because the SH5400 is non-impact, we'll also verify that your county doesn't require impact glazing.
No — EnergyVue is a non-impact vinyl line, so it cannot be installed in the High-Velocity Hurricane Zone of Miami-Dade and Broward, and it isn't the right choice for any opening that needs a Notice of Acceptance. It belongs on inland Florida addresses where the building code does not require laminated impact glazing. If you're inside the HVHZ or you want storm protection regardless of jurisdiction, the impact counterpart is WinGuard Vinyl, which uses the same frame.
EnergyVue is the line for projects driven by the energy bill rather than the wind map. It posts the best thermal performance in PGT's residential catalog — U-factors from about 0.27 to 0.32 with the EnergyShield Max Low-E package — which is low enough to move a utility bill and clear ENERGY STAR for the climate zone. The welded vinyl frame also resists salt-air corrosion and never needs repainting. We spec it for inland, energy-focused homes where impact glass isn't required by code.
PGT has built impact windows and doors in Venice, Florida since 1980 and is the largest impact-window and -door manufacturer in the country. It was the first company to develop impact-resistant products that met Miami-Dade County's hurricane code after Hurricane Andrew, and the line is engineered specifically for Florida conditions. PGT is now part of the MITER Brands family, alongside WinDoor, ECO, and NewSouth, but the products are still made in Florida under the PGT name.
