MG-6000 Impact Storefront Wall (heavy spec)
Heavy-spec aluminum impact storefront wall at 145 psf positive and negative, the highest commercial design pressure in the Mr Glass catalog. Panels up to 48 by 144 inches.
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +100/-145 psf
Energy
Made in Florida
Impact protection, built for South Florida
The MG-6000 is Mr Glass's heavy-spec impact storefront wall, rated to the highest design pressure in the commercial line at 145 psf positive and negative. Specified for South Florida coastal commercial projects where exposure category and ASCE 7 thresholds require elevated load capacity. Panel sizes up to 48 by 144 inches with LMI impact rating.
- Florida Building Code product-approved
- Large-missile impact-rated laminated glass
- Energy-efficient Low-E insulated glass options to control heat gain
- Professionally installed across South Florida by Armor Pro
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Max Size
48 x 144 in
Design Pressure
+100/-145 psf
Impact Rating
LMI
Sizes & Pressures
| Configuration | Max size | Design pressure |
|---|---|---|
| Impact Resistant Storefront Wall System (multiple units) | 48 x 144 in | +100/-145 psf |
Glass & Energy Performance
| Glass package | U-Factor | SHGC | VT |
|---|---|---|---|
| 9/16" Laminated Clear: 1/4" Clear HS + 0.09 PVB + 1/4" Clear HS | 1.03 | 0.599 | 0.701 |
| 9/16" Laminated Gray: 1/4" Gray HS + 0.09 PVB + 1/4" Clear HS | 1.03 | 0.452 | 0.352 |
| 1-5/16" Insul Laminated w/ SB70: 1/4" Clear HS (SB70 #2) + 0.09 PVB + 1/4" Clear HS + 1/2" Air + 1/4" Clear FT | 0.701 | 0.234 | 0.442 |
| 1-5/16" Atlantica Insul Laminated w/ SB70: 1/4" Atlantica HS + 0.09 PVB + 1/4" Clear HS (SB70 #3) + 1/2" Air + 1/4" Clear FT | 0.686 | 0.258 | 0.34 |
| 1-5/16" Insulated Laminated Gray: 1/4" Gray HS + 0.09 PVB + 1/4" Clear HS + 1/2" Air + 1/4" Clear FT | 0.682 | 0.356 | 0.322 |
| 9/16" Laminated Clear w/ SB70: 1/4" Clear (SB70 surface#2) + 0.090 PVB + 1/4" Solargray | 1.067 | 0.222 | 0.246 |
| 9/16" Laminated Clear w/ SB60 face#2: 1/4" Clear (SB60 surface#2) + 0.090 PVB + 1/4" Solargray | 1.067 | 0.311 | 0.295 |
| 9/16" Laminated Solargray w/ SB60 face#3: 1/4" Solargray + 0.090 PVB + 1/4" Clear (SB60 surface#3) | 1.067 | 0.322 | 0.246 |
| 9/16" Laminated Solargray w/ SB60 face#2: 1/4" Solargray (SB60 surface#2) + 0.090 PVB + 1/4" Clear | 1.067 | 0.353 | 0.295 |
| 9/16" Laminated Clear w/ SB70 face#2: 1/4" Clear (SB70XL face#2) + 0.090 PVB + 1/4" Clear | 1.067 | 0.282 | 0.492 |
Performance Certifications
Energy-performance data on file (manufacturer-published; not third-party certified).
- FL18411.R3
Options
Ready to install the MG-6000 Impact Storefront Wall (heavy spec)?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Frequently Asked Questions
The MG-6000 is Mr Glass's heavy-spec impact storefront wall, rated to 145 psf positive and negative, the highest commercial design pressure in the Mr Glass catalog. We specify it for South Florida coastal commercial projects where the exposure category and ASCE 7 wind-load thresholds call for elevated load capacity. It is the storefront tier to reach for when the standard commercial systems don't carry enough design pressure for the site.
Yes. The MG-6000 is a large-missile impact (LMI) system approved for the High-Velocity Hurricane Zone, carrying Florida Product Approval FL18411.R3. Its 145 psf rating makes it well suited to high-load coastal commercial envelopes. We'll confirm the applicable approval and the rating for your specific opening at quote.
The MG-6000 storefront wall system uses panels up to 48 by 144 inches, rated to +100/-145 psf in the multi-unit configuration. That 145 psf negative design pressure is the top of the Mr Glass commercial line. We'll lay out the panel sizes and confirm the design pressure your project requires when we review the openings.
The MG-6000 offers laminated and insulated-laminated impact glass with a PVB interlayer. The 9/16-inch laminated packages run about a U-factor of 1.03 to 1.07, while the 1-5/16-inch insulated-laminated options improve to roughly U 0.68 to 0.70. With Solarban SB70, SB70XL, or SB60 Low-E coatings, SHGC can drop to around 0.22, and tints include clear, gray, Solargray, and Atlantica, so we'll help tune solar control and daylight for the building.
The MG-6000 aluminum frame comes with a standard AAMA 2604 powder-coat finish (5-year warranty), with an upgraded AAMA 2605 finish (10-year warranty) available for more demanding coastal exposure or a longer finish life. We can review color and finish options with you so the storefront matches the building's design and durability needs.
Installed pricing for the MG-6000 depends on the panel layout and sizes, the glass package and tint, the frame finish, and the building's structure and required design pressure. Because this is a heavy-spec impact storefront rated to 145 psf with panels up to 48 by 144 inches, every project is priced individually. Armor Pro provides a free, no-obligation estimate after reviewing the project and measuring the openings.
Mr Glass runs a deep catalog, and we install across most of it. On the residential side that means impact windows in single-hung, horizontal-roller (sliding), fixed picture, and casement and awning styles, plus a full range of doors: entry and outswing doors, architectural pivot doors, and sliding glass doors including the multitrack pocket slider. They also build a commercial line of impact and non-impact storefronts, window walls, curtain walls, glass railings, and aluminum louvers that we handle on light-commercial projects. We help you match the right Mr Glass product to each opening and pull the matching approval for your county.
Most of the line is, but it depends on the specific product. Mr Glass's premium residential windows are dual-certified to both Large Missile Impact (LMI) and Small Missile Impact (SMI), which covers them for high-rise and coastal work anywhere in the High-Velocity Hurricane Zone of Miami-Dade and Broward. Their value-tier windows and all of their doors carry the impact certification needed for the HVHZ as well, and a couple of commercial products (the MG-275 door and MG-4500 storefront) are non-impact and are not used in the wind-borne-debris zone. We confirm the exact product, rating, and approval for your address before we quote and permit.
