MG-2000 Impact Resistant Curtain Wall
Impact-resistant aluminum curtain wall for mid-rise and high-rise commercial, dual LMI+SMI certified. R7 revision, the most-iterated commercial NOA in the catalog.
Florida DBPR
Approved
Impact Rating LMI/SMI
Design Pressure +90/-100 psf
Energy
Made in Florida
Impact protection, built for South Florida
The MG-2000 is Mr Glass's impact-resistant aluminum curtain wall system for mid-rise and high-rise commercial buildings, dual- certified to both LMI and SMI impact ratings. The most-iterated commercial Florida Product Approval in the catalog, currently at R7 revision. Rated to 100 psf positive and negative design pressure for South Florida coastal commercial high-rise installations.
- Florida Building Code product-approved
- impact-rated laminated glass
- Energy-efficient Low-E insulated glass options to control heat gain
- Professionally installed across South Florida by Armor Pro
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Energy Efficient
Low-E insulated glass options reduce heat gain
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Max Size
150 in
Design Pressure
+90/-100 psf
Impact Rating
LMI/SMI
Sizes & Pressures
| Configuration | Max size | Design pressure |
|---|---|---|
| Curtain Wall System (standard mullion) | 150 in | +90/-100 psf |
| Curtain Wall System (heavy mullion) | 208 in | +90/-100 psf |
Glass & Energy Performance
| Glass package | U-Factor | SHGC | VT |
|---|---|---|---|
| 9/16" Laminated Clear: 1/4" Clear HS + 0.09 PVB + 1/4" Clear HS | 0.95 | 0.655 | 0.768 |
| 9/16" Laminated Clear w/ SB70: 1/4" Clear (SB70 surf#2) HS + 0.09 PVB + 1/4" Clear HS | 0.949 | 0.292 | 0.537 |
| 9/16" Laminated Gray: 1/4" Gray HS + 0.09 PVB + 1/4" Clear HS | 0.949 | 0.487 | 0.36 |
| 9/16" Laminated Gray w/ SB70: 1/4" Gray HS (SB70 #2) + 0.09 PVB + 1/4" Clear HS | 0.949 | 0.336 | 0.269 |
| 1-5/16" Insulated Laminated Clear w/ SB70: 1/4" Clear FT (SB70 #2) + 1/2" Air (alum spacer) + 1/4" Clear HS + 0.09 PVB + 1/4" Clear HS | 0.391 | 0.247 | 0.552 |
| 1-5/16" Insulated Laminated Clear: 1/4" Clear FT + 1/2" Air + 1/4" Clear HS + 0.09 PVB + 1/4" Clear HS | 0.539 | 0.599 | 0.686 |
| 1-5/16" Insulated Laminated Gray w/ SB70: 1/4" Gray (SB70 #2) + 1/2" Air + 1/4" Clear HS + 0.09 PVB + 1/4" Clear HS | 0.391 | 0.182 | 0.289 |
| 1-5/16" Insulated Laminated Starfire w/ SB70: 1/4" SB72 #2 + 1/2" Air + 1/4" SB90 Starfire + 0.09 PVB + 1/4" Starfire | 0.476 | 0.191 | 0.297 |
| 1-5/16" Insulated Laminated Starfire w/ SB70 (structural silicone): 1/4" Starfire SB72 #2 + 1/2" SS air spacer + 1/4" Starfire + 0.09 PVB + 1/4" Starfire | 0.476 | 0.23 | 0.556 |
Performance Certifications
Energy-performance data on file (manufacturer-published; not third-party certified).
- FL27401.R7
Options
Ready to install the MG-2000 Impact Resistant Curtain Wall?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Frequently Asked Questions
The MG-2000 is Mr Glass's impact-resistant aluminum curtain wall system, built for mid-rise and high-rise commercial buildings rather than single-family homes. It creates a continuous glazed exterior wall for South Florida coastal commercial high-rise projects. We install it on commercial envelopes where large, continuous spans of impact glazing are required.
Yes. The MG-2000 is dual-certified to both LMI and SMI impact ratings, so it qualifies for High-Velocity Hurricane Zone installations including high-rise. It carries Florida Product Approval FL27401.R7, which is the most-iterated commercial approval in the Mr Glass catalog. We'll confirm the approval applies to your specific building and elevation at quote.
The MG-2000 comes in a standard-mullion configuration spanning up to 150 inches and a heavy-mullion configuration spanning up to 208 inches in height. It's rated to roughly +90 to +100 psf positive and -100 to -110 psf negative design pressure for coastal commercial high-rise. We confirm the mullion type and design pressure your project's wind loads require before specifying the system.
The MG-2000's standard 9/16-inch laminated glass runs around U 0.95, but its 1-5/16-inch insulated laminated packages with Low-E (Solarban SB70) drop the U-factor to about 0.391 and the SHGC to roughly 0.18-0.25, strong performance for a commercial envelope. There's also a Starfire low-iron option for higher clarity. We'll match the glass build to your building's energy code and solar control needs.
The MG-2000 frame uses a powder-coated aluminum finish, with AAMA 2604 standard (5-year warranty) or upgraded AAMA 2605 (10-year warranty) for greater durability on tall commercial exposures. Glass tints include Clear, Gray, Bronze, Solex Green, and Solargray, plus Low-E coatings (Solarban SB70/SB70XL/SB60) and privacy interlayers. We'll coordinate finish and tint to match the building's design specifications.
The installed cost of an MG-2000 curtain wall depends heavily on the size of the wall, the mullion configuration (standard versus heavy), the glass package, and the building and elevation it goes on, since it's a commercial high-rise system. There's no flat price for a project of this scale. Armor Pro provides a free estimate so you get an accurate installed figure for your building.
Mr Glass runs a deep catalog, and we install across most of it. On the residential side that means impact windows in single-hung, horizontal-roller (sliding), fixed picture, and casement and awning styles, plus a full range of doors: entry and outswing doors, architectural pivot doors, and sliding glass doors including the multitrack pocket slider. They also build a commercial line of impact and non-impact storefronts, window walls, curtain walls, glass railings, and aluminum louvers that we handle on light-commercial projects. We help you match the right Mr Glass product to each opening and pull the matching approval for your county.
Most of the line is, but it depends on the specific product. Mr Glass's premium residential windows are dual-certified to both Large Missile Impact (LMI) and Small Missile Impact (SMI), which covers them for high-rise and coastal work anywhere in the High-Velocity Hurricane Zone of Miami-Dade and Broward. Their value-tier windows and all of their doors carry the impact certification needed for the HVHZ as well, and a couple of commercial products (the MG-275 door and MG-4500 storefront) are non-impact and are not used in the wind-borne-debris zone. We confirm the exact product, rating, and approval for your address before we quote and permit.
Curtain wall, storefront, window-wall, and related framing systems for commercial and multi-family buildings, including impact-rated assemblies for the High-Velocity Hurricane Zone. These are engineered, project-specific systems rather than off-the-shelf units.
