Eco-Guard Single Hung Series
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +80/-120 psf
Made in Florida
Eco-Guard Single Hung Series 150
ECO's aluminum impact single hung — the workhorse South Florida HVHZ window.
High-pressure aluminum impact single hung on a 3-3/8 in. frame, +80/-120 psf, LMI+SMI — ECO's strongest single hung for coastal HVHZ openings.
Florida DBPR
Approved
Impact Rating LMI
Design Pressure +80/-120 psf
Made in Florida
Impact protection, built for South Florida
- Florida Building Code product-approved
- Aluminum frame engineered for strength and durability
- Large-missile impact-rated laminated glass
- Corrosion-resistant finishes for coastal applications
- Professionally installed across South Florida by Armor Pro
Configurations
X = operable panel (it opens) · O = fixed panel (doesn’t open). Panels read left‑to‑right as viewed from outside (hung windows read top‑to‑bottom). Example: XO = operable on the left, fixed on the right.
Impact Protection
Tested to withstand hurricane wind-borne debris
Engineered Strength
Built and tested to Florida product-approval standards
Corrosion Resistant
Coastal-grade finishes for salt-air durability
Limited Warranty
Manufacturer warranty plus Armor Pro install workmanship
At a Glance
Frame Material
Aluminum
Max Size
53.125 x 96 in
Design Pressure
+80/-120 psf
Impact Rating
LMI
Sizes & Pressures
| Configuration | Min size | Max size | Design pressure |
|---|---|---|---|
| Single Hung | 19.125 x 26 in | 53.125 x 96 in | +80/-120 psf |
Performance Certifications
- FL26972.R2
- FL40096
Options
Related Products
More models in the Eco-Guard Single Hung Series.
Ready to install the Eco-Guard Single Hung Series 150?
Armor Pro measures, permits, and installs it across South Florida — code-compliant and warrantied. Get a free, no-obligation estimate.
Comparable from Other Brands
Other single hung models Armor Pro installs.
Frequently Asked Questions
The Eco-Guard Series 150 is ECO Window Systems' high-pressure aluminum impact single hung, the strongest single hung in the line. It's built on a deeper 3-3/8 in. heavy-gauge T6 aluminum frame with stainless hardware and Eco-Guard laminated impact glass. We reach for the Series 150 on coastal South Florida openings where design pressures climb beyond what the Series 50 or 100 cover.
The Series 150 is Large Missile Impact (LMI) plus Small Missile Impact (SMI) rated and reaches up to +80/-135 psf, the highest of ECO's single hungs and the reason we use it on high-load coastal openings. It's HVHZ-approved under Florida Product Approval FL40096 for Miami-Dade and Broward. We confirm the exact rating your opening requires during permitting.
The Series 150 runs from 19-1/8 by 26 in. up to 53-1/8 by 96 in. in a single hung configuration, taller than the 76 in. maximum on the Series 100. That extra height, combined with the deep 3-3/8 in. frame, is what lets it hold the +80/-135 psf rating. We measure your opening and confirm the size and rating before ordering.
The Series 150 offers four impact glass packages: 7/16 in. laminated with a .090 in. Trosifol PVB interlayer (G1), 15/16 in. insulated laminated with PVB (G2), 7/16 in. laminated with SentryGlas (G3), and 15/16 in. insulated laminated with SentryGlas (G4). The insulated options add a second pane for better energy performance, and the SentryGlas interlayer is a stiffer, stronger laminate than standard PVB. We'll match the glass package to your wind load and energy goals at quote.
Choose the Series 150 when your opening faces higher design pressures, since it reaches +80/-135 psf on a deeper 3-3/8 in. frame and goes up to 96 in. tall, versus the 2-3/4 in. Series 100 at +75/-141.1 psf and 76 in. The Series 100 remains a strong, more economical pick for typical inland HVHZ replacements. We'll recommend the right series for your wind zone when we measure.
Installed price depends on the size of the window, which of the four glass packages you choose, and the condition of the existing opening, so there's no single number. As ECO's strongest single hung with optional SentryGlas and insulated glass, the Series 150 typically prices above the Series 50 and 100. Armor Pro provides a free, no-obligation estimate.
A single hung has two stacked sashes in one frame: the bottom sash slides up and down to open while the top sash stays fixed. It's the most common operation style on South Florida homes because it ventilates well, takes up no swing space, and is straightforward to screen. ECO's aluminum single hung family runs from the entry Series 50 up to the heavier Series 150.
All three ECO single hungs use Eco-Guard laminated impact glass on heavy-gauge aluminum frames and carry large-missile impact (LMI) approval, with the Series 100 and 150 adding small-missile coverage. They run under Florida Product Approval FL40096 for Miami-Dade and Broward HVHZ work. Low-E and laminated insulating glass with argon are available where you want to cut heat gain.
Yes. ECO's residential aluminum impact lines carry Miami-Dade Notices of Acceptance and Florida Product Approvals, which makes them eligible to install in the High-Velocity Hurricane Zone (Miami-Dade and Broward counties). The exact wind ratings depend on the specific series, size, and configuration, so we confirm the right product for your opening on the quote. We pull the permit and submit the approval documents as part of every job.
